Distributed Antenna Systems for New Construction in Atlanta

JB Technologies is a certified Nextivity Pro Partner — we design, install, and commission CEL-FI QUATRA active DAS and passive DAS systems for commercial cellular coverage.

DAS Installation Services for New Construction Projects in Atlanta

Atlanta's new-construction pipeline runs broad and deep — corporate campuses in Buckhead and Cumberland, mixed-use high-rises in Midtown and West Midtown, hospitality and convention work near the airport and downtown, and tech-office expansions along the BeltLine. JB Technologies is headquartered in Kennesaw and designs and installs DAS across the metro daily. We understand the donor-signal realities of a low-altitude inland market with mature carrier infrastructure and the specific permit and inspection cadences of every major municipality from City of Atlanta DPCD through Fulton, DeKalb, Cobb, and Gwinnett.

Local context — Atlanta, GA

Metro Atlanta is the densest carrier-macro environment in the Southeast — Verizon, AT&T, and T-Mobile all have aggressive site grids in the core, so outdoor donor signal is rarely the limiting factor for new construction inside the Perimeter. The real DAS challenge is the building stock: Midtown and Buckhead Class A towers from the last decade lean heavily on Low-E spectrally selective glass and post-tensioned concrete floor plates, which together attenuate cellular signal 18-25 dB versus older steel-and-tempered-glass construction. Below-grade parking is the consistent failure mode — three- and four-level garages under Midtown towers routinely measure no usable signal on any carrier. The City of Atlanta's DPCD permits cellular DAS on the low-voltage track, but BeltLine-adjacent projects in DeKalb or unincorporated Fulton route differently, which our team handles transparently for GCs. Severe-weather lightning density across north Georgia also drives conservative bonding and grounding practice on every rooftop donor antenna.

Why Choose JB Technologies for DAS in Atlanta?

• Certified Nextivity / CEL-FI QUATRA Integrator
• Measurement-Driven RF Site Surveys and iBwave Design
• Multi-Carrier Coordination — Verizon, AT&T, T-Mobile
• FCC Part 90 / Part 22 / Part 24 Signal-Source Compliance
• Commissioning Sweeps and As-Built Documentation

What is DAS?

A Distributed Antenna System (DAS) is an engineered network of indoor antennas that distributes commercial cellular signal throughout a building so that tenants, employees, and visitors get reliable voice and data coverage on Verizon, AT&T, and T-Mobile. DAS solves the in-building coverage problem in two architectures. Passive DAS uses a donor antenna on the roof feeding a bi-directional amplifier and a coax-and-splitter distribution grid — cost-effective for buildings under roughly 150,000 square feet with a usable outdoor donor signal. Active DAS converts RF to digital at a head-end and distributes over fiber to remote units, scaling cleanly to multi-million-square-foot venues and supporting all major carriers through carrier-grade signal sources. When the outdoor donor is strong and the building is mid-sized, a single-carrier CEL-FI QUATRA deployment is often the right answer; when the donor is weak, the building is large, or true multi-carrier parity is needed, an active DAS is the durable choice.

Where DAS makes sense

DAS is owner- and tenant-driven — it is the answer to "why does my phone drop calls inside this building?" rather than a building-code mandate. Typical DAS candidates:

1. Large floor plates — offices, hospitals, and campuses over roughly 50,000 sq ft where a single booster cannot cover the area.
2. Dense concrete or steel construction — hardened cores and rebar-heavy slabs attenuate cellular signal 15–25 dB.
3. Impact-rated or low-E glass — modern energy-efficient and hurricane-impact glazing attenuates PCS and AWS bands 10–18 dB.
4. Multi-carrier requirements — tenants and visitors on Verizon, AT&T, and T-Mobile all need parity coverage.
5. Below-grade and parking levels — basements, parking decks, and tunnels where macro signal does not penetrate.
6. Healthcare facilities — nurse-call workflows, BYOD clinical apps, and patient-experience requirements.
7. Hotels and mixed-use towers — in-room and amenity-floor cellular is a guest-experience expectation.
8. Warehouses and distribution centers — metal-clad envelopes and dock-door geometry that block macro signal.
9. Higher-education buildings — libraries, residence halls, and student centers with dense user counts.
10. Stadiums, arenas, and conference venues — capacity-driven deployments, not just coverage.

Typical system costs.

DAS pricing varies with building size, donor-signal strength, carrier mix, and design topology. Two rough ranges hold across most commercial work:

Installed Cost Ranges

• Passive DAS — $0.75 to $1.50 per square foot for single-carrier or limited multi-carrier deployments with a clean donor signal, typical of mid-sized offices and mid-rise residential.
• Active multi-carrier DAS — $2.50 to $5.00 per square foot, driven by remote-unit count, fiber backbone length, carrier signal-source coordination, and AHJ requirements. Hospitals, stadiums, and campus deployments live in this range.
• RF site survey and design package — typically $1,500 to $5,000 depending on building footprint and the number of carriers in scope.
• Factors that drive cost:
  • Donor signal strength — weak outdoor RSSI may force a tower-mounted amplifier, an off-air bi-directional amp upgrade, or a small-cell signal source.
  • Building materials — concrete, low-E glass, impact glazing, and metal cladding each shift the design.
  • Carrier mix — single-carrier QUATRA units are cheaper than tri-carrier active head-ends, and each added carrier requires its own Letter of Authorization.
  • Retrofit vs new construction — pulling fiber and coax in finished spaces costs materially more than rough-in during the shell stage.

Permitting and Carrier Coordination

• Electrical and low-voltage permits — required in most jurisdictions for head-end power and cable distribution.
• Carrier Letters of Authorization (LOAs) — active DAS using signal sources from Verizon, AT&T, or T-Mobile requires per-carrier LOAs and RF-emissions disclosure under FCC Part 90, Part 22, and Part 24.
• FCC signal-booster registration — consumer-class boosters must be registered with the operating carrier; commercial Part 20.21 systems are coordinated upfront.

Commissioning and Ongoing Support

• Commissioning sweeps — downlink and uplink RSSI measured at design points, exported to the building owner and the AHJ when applicable.
• Annual coverage verification — recommended after major tenant fit-outs, antenna relocations, or carrier band-plan changes.
• Warranty and remote monitoring — QUATRA and most active DAS head-ends ship with cloud monitoring; JBT maintains active alarms through a service agreement.

Key Takeaways

• Plan during shell construction — rough-in for fiber and coax pays back many times over versus a finished-space retrofit.
• Match the topology to the building — passive for smaller buildings with good donor, active for large or multi-carrier requirements.
• Confirm carriers early — the carrier mix dictates equipment selection, LOAs, and design timeline.
